Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Cantonk
Model Number:
KHJSL200W
Type:
IP Camera
Style:
Mini Camera
Sensor:
CMOS
Technology:
NetWork
Special Features:
Waterproof / Weatherproof
Product name:
2017 Cantonk 2MP Mini Wireless WIFI CCTV camera
Resolution:
2MP
Solution:
IMX290 Hi3516D
Lens:
Board Lens 2.8mm
Feature:
1/2.8" SONY Starvis Back-illuminated CMOS Sensor
Size:
36(W) x 36(H) x27(D)mm
Weight:
300g
Warranty:
Two Years
Certificate:
ISO FCC CE RoHS
Keyword:
mini camera wifi
Packaging & Delivery
Packaging Details
Neutral package or customers' design package
Delivery Time
5-7 working days after payment for sample order
2017 Cantonk 2MP Mini Wireless WIFI CCTV camera
Product Description
| Model NO. | KHJSL200W | ||
| Camera | |||
| Image Sensor | IMX290 | ||
| Main processor | HI3516C | ||
| Resolution | 1080P | ||
| Effective Pixels | 1945(H)*1097(V) | ||
| TV System | PAL/NTSC | ||
| Electronic Shutter Time | Auto: PAL 1/1-1/10000Sec; NTSC 1/1-1/10000Sec | ||
| Sync System | Internal | ||
| Usable Illumination | 0.01Lux | ||
| Audio | 2-way audio | ||
| SD Card | support 128G Micro SD | ||
| Video Output | Network | ||
| Lens | |||
| Focus Length | Board Lens 2.8mm/F2.8 | ||
| Focus Control | Fixed | ||
| Lens Type | Fixed | ||
| Pixels | 3M Pixels | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Protocol | IPv4, HTTP, TCP/IP, FTP, NTP, RTSP, UDP, SMTP, DNS, DDNS | ||
| ONVIF | Support ONVIF 2.4 | ||
| P2P | YES, Support QR Code | ||
| POE | Optional(External POE But Without Audio and Alarm Functions), Support IEEE 802.3afOptional, Support IEEE 802.3af | ||
| WIFI | Optional | ||
| Video Delay | 0.3S (Within the Lan) | ||
| Main Stream | 1920*1080@30fps | ||
| Sub Stream | 720*480@30fps | ||
| IE Brower | IE6-11 | ||
| Smart Phone | iPhone, iPad, Android, Android Pad | ||
| Camera Features | |||
| Day/Night | Color/ B&W (IR-CUT ) | ||
| Compression | H.264/H.265 | ||
| Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control) | ||
| Motion Detection | Support | ||
| Privacy Masking | 3 Rectangular Zone | ||
| WDR | Support | ||
| Recording Mode | NVR/NAS/CMS/Web | ||
| Language | Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian | ||
| General | |||
| Housing | Mental | ||
| IR Cut Filter | No | ||
| Operation Temperature | -20℃ ~ 60℃ RH95% Max | ||
| Storage Temperature | -20℃ ~ 60℃ RH95% Max | ||
| Power Source | DC12V±10%, 100mA | ||
| Dimension | 36(W) x 36(H) x33(D)mm | ||
| Weight | 300 | ||
- Size: 2.409
- Place of Origin: China
- Brand Name: Cantonk
- Model Number: WIFIPG498RH400
- Weight: 6.400 kg
Why choose us?
1.14 years experience in exportation all over the world
2.2000 Employees, 50000 Square Meters,20 Production Lines
3.Passed CE,FCC,ROHSand ISO9001:2008 certificate!
4.Our own SMT Production line,housing and mould factory
5. 2 years warranty
6.5 times QC testing
7.OEM,ODM service
1. ODM Services:
a. Logo
Please offer us your own high resolution logo in JPG format;
There should be two colors at most in the logo;
There should be no gradient effect in the logo
b. Label and Manual
Please offer us your own model numbers
Other requirements
2. OEM Services:
a. Logo
Please offer us your own high resolution logo in JPG format;
There should be two colors at most in the logo;
There should be no gradient effect in the logo
b. Label
Please offer us your own model numbers
Other requirements
c. Manual
Please offer us the finished manual file that can be printed directly.
d. Packing Box
We will offer you the dimension and the design file;
Please design your own style based on this file then send it back to us;
We will print some samples for your checking;
e. The Whole Camera/DVR
Housing: Please offer us the housing design file then we will offer you a sample for your checking;
Requirement on other parts
Lead time:
1. Sample orders will be delivered from our factory within 5 working days.
2. General orders will be delivered from our factory within 12 working days.
3. Big orders will be delivered from our factory within 19 working days at most.
Payment Terms:
1. Telegraphic Transfer (T/T)
a. Usually we accept 100% T/T in advance;
b. Subjected the order amount, we can accept 30% deposit T/T in advance 70% balance T/T before the shipment.
Note: When you make the payment, please write down the PROFORMA INVOICE (PI) NUMBER on the bank receipt as the reference.
2. PayPal
4% commission charges will be added into the amount.
3. Letter of Credit (L/C)
a. On condition that order amount reaches our request then we will accept L/C;
b. We accept L/C at sight only;
4. OA 30days
a. On condition that order amount reached our target then we will accept OA 30days
