- Size: 400*75*1300MM
- Place of Origin: China
- Brand Name:
- Model Number: P-B3601
- Weight: 1.700 kg
Model | Inner Box Size | Carton Size | Q'ty/CTN | G.W. |
165*1215mm | 250*75*1300mm (1/2) | 1320*170*270 MM | 4PCS/Carton | 13.6kg |
315*1215mm | 400*75*1300mm(1/2) | 1320*170*420 MM | 4PCS/Carton | 21.8kg |
1. With External power supply, Driver input voltageAC85-265V, 50/60Hz; Lighting input voltageDC25-42V, Constant current.
2. PF>0.95, Power Efficiency: >0.85
3. Material: AL PMMA PC Diffuser
4. Protection grade IP20; Insulation class II.
5. Ambient temperature:-20°C~45°C, Surface temperature: 42°C~45°C; Relative humidity 10%-80%RH.
6. Energy-saving, Super bright, environmental-friendly, saving 65% energy than the traditional panel lights.
7. Uniform light output, bright and comfortable, alleviating eye fatigue, wide beam angle.
Under the condition of voltage instability, the LED panel light could work properly by using the constant-current LED driver.
- Size: 400*75*1300MM
- Place of Origin: China
- Brand Name:
- Model Number: P-B3601
- Weight: 1.700 kg
Product Spec.: P-B3602
(Electrical Characteristics) | (Optical Properties) | ||
Power Supply | With External Constant Current Power Supply | LED Type | SMD2835(0.5W) |
Input Voltage | AC100-240V / 50-60Hz | THD | <20 |
Working Voltage | DC25-42V 1000mA | Lumen | 80LM/W |
Power | 36W | CRI | ≧80 Ra |
Power Factor | 0.95 | Beam Angle | 120° |
Life Time | ≧50000H | CCT | WW:2500-2800K 2800-3200K DW:3750-4250K PW:4750-5250K 5500-6500k |
(Standard Dimensions) | |||
Product Dimension | N.W. | Packing Dimension | G.W. |
295*1195*10 mm | 3.2 kg | 1*2pcs 400*75*1300mm | 8.8 kg |
