- Size: 53
- Place of Origin: China
- Brand Name:
- Model Number: PH
- Weight: 2.300 kg
| Specification of Ephan 5 Years Warranty 100lm/W LED Linear Recessed Light | |||
| Model: EPL-R7075 | |||
Aluminum Profile
| Material | AL6063 aluminum | |
| Size | W70xH75mm, custom-made length | ||
| Surface Treatment | anodizing | ||
| Color | silver, white, black, or any other color | ||
| IP Range | IP44/IP65/IP67 | ||
| Application | indoor | ||
| Installation Type | recessed | ||
| Lampshade | Material | PMMA/PC | |
| Type | clear, semi-clear, milky white, stripe | ||
| Shape | plain | ||
| Transmittance | >85% | ||
| LED | LED Type | SMD2835 | |
| Brand of LED Chip | Epistar/Samsung | ||
| CRI | >80 | ||
| SDCM | <5 | ||
| Color Temperature | warm white: 2800~3500K netural white: 4000~4500K pure white: 6000~6500K cool white: 9000~12000K | ||
| Luminous | 80~100lm/W | ||
| Internal Driver | Function | Emergency system | |
| Brand | Lifud | ||
| Working Mode | constant voltage or constant current | ||
| Input Voltage | AC85~265V | ||
| Frequency | 50~60Hz | ||
| Wattage | 20W/30W/40W | ||
| Power Factor | 0.9 | ||
| Dimmable | 0~10V | ||
| Other | Warranty | 3 years | |
| Lifetime | 50,000hrs | ||
| Working Temperature | -20 ~ 45 celsuis degree | ||
| Storage Temperature | -40 ~ 60 celsuis degree | ||
| Accessories | fastener x 2pcs | ||
- Size: 53
- Place of Origin: China
- Brand Name:
- Model Number: PH
- Weight: 2.300 kg
1 Product shell: use pure 6063 aluminum, with surface coating processing.
2 Product wire slot: use 2.5 square 7-wires structure, can share dimming and emergency function.
3 Product installation: use patented mechanical lock structure, make it easy to install lamp body and wire slot.
4 This product use SMD2835 0.5W, the highly bright light source. Use the less than 1/2 load
power to reduce the product light decay, the light efficiency of the product can reach to 125LM/W.
5 This product can be linked to “一? shape, ?T? shape and ?L? shape, meet the need of lamp layout for different places. Linking structure use patented butterfly handle to mechanically fix, make it easy to install.
6 Product outlet wire way: can be used in side outlet wire and back side outlet wire, easy for different installation ways.
7 This product will be fitted with hanging wire, hanging chain and mounting bracket.Ceiling or Hanging are optional.
Shipping of Linear Light
| Destination | Method | Fee | Timing (changeable) | Custome Clearance |
| door to door | EMS | charge by volumn weight | 10~30 days | Forwarder |
| DHL/Fedex | 5~12 days | |||
| UPS/TNT | ||||
| airport | by air | Yourself | ||
